Palier - UCT 213 ZKL

Description technique

The UCT 213 take-up bearing unit is engineered for material handling applications, providing reliable support and alignment for conveyor systems and similar machinery. Technical Specifications: Housing Material: Cast iron Bearing Type: Radial insert ball bearing Locking Mechanism: Set screw in the inner ring Sealing Solution: Standard seals with additional flingers Dimensions: d (Shaft Diameter): 65 mm d₁ (Housing Bore Diameter): 82.5 mm A (Housing Length): 126 mm B (Housing Height): 168.3 mm H (Mounting Height): 167 mm L (Center to Center Distance): 225 mm Performance Data: Basic Dynamic Load Rating (C): 57.2 kN Basic Static Load Rating (C₀): 40 kN Fatigue Load Limit (Pu): 1.7 kN Limiting Speed: 2350 rpm with shaft tolerance h6 Mounting Information: Set Screw Size: M10x1 Hexagonal Key Size for Set Screw: 5 mm Recommended Tightening Torque for Set Screw: 16.5 N·m Included Components: Housing: T213 Bearing Insert: UC213/H Associated Products: End Cover: ECY 213 This unit is designed to provide robust support and alignment in material handling systems, ensuring efficient operation and longevity of the machinery.
