Palier - UCFC 210 NTN

Description technique

The NTN UCFC 210 is a four-bolt round flange bearing unit that offers robust support and durability for shaft applications. Key Features: Bearing Type: Ball bearing Locking Device: Set screw Seal Type: Contact seal Seal Material: Nitrile rubber Housing Material: Cast iron Housing Construction: One-piece design End Type: Open Performance: Light duty Dynamic Load Rating: 35,000 N (7,850 lbf) Static Load Rating: 23,200 N (5,200 lbf) Maximum Rotational Speed: 3,100 RPM Operating Temperature Range: -40 to 120°C (-40 to 250°F) Lubrication: Non-relubricatable Dimensional Specifications: Shaft Diameter (d): 50.000 mm (1.9685 in) Overall Length (L): 165.0 mm (6.5000 in) Bolt Circle Diameter (J): 138.0 mm (5.4375 in) Bolt Hole Diameter (J1): 97.6 mm (3.8437 in) Housing Height (A): 40.0 mm (1.5781 in) Housing Height from Mounting Surface (A0): 54.600 mm (2.1562 in) Housing Height from Mounting Surface (A1): 28.0 mm (1.0937 in) Housing Height from Mounting Surface (A2): 10.0 mm (0.3906 in) Housing Height from Mounting Surface (A3): 12.0 mm (0.4687 in) Housing Height from Mounting Surface (H3): 110.0 mm (4.3307 in) Bolt Hole Diameter (N): 16.0 mm (0.625 in) Housing Width (B): 51.600 mm (2.0315 in) Bolt Hole Diameter (S): 19 mm (0.748 in) This bearing unit is ideal for applications requiring a reliable and durable bearing solution with easy installation and maintenance.
