Palier - SNL 512 610 SKF

Description technique

The SKF SNL 512-610 V is a high-quality split plummer block housing engineered for reliable bearing support in demanding environments. Its durable cast iron construction ensures long-lasting performance and ease of maintenance.​ Technical Specifications: Housing Type: Split plummer block (pillow block) Material: Cast iron Bore Diameter (Da): 110 mm Width of Bearing Seat (Ca): 48 mm Centre Height (H1): 70 mm Overall Length (L): 255 mm Overall Height (H): 134 mm Foot Height (H2): 30 mm Foot Width (A1): 70 mm Overall Width (A): 105 mm Distance Between Attachment Bolts (J): 210 mm Attachment Bolt Hole Diameter (N): 24 mm Attachment Bolt Hole Width (N1): 18 mm Thread for Relubrication Holes (G11/8-27 NPSF): Yes Seal Grooves: Inside Width Between Seal Grooves (A3): 80 mm Width of Seal Groove (A4): 5 mm Distance to Seal Groove Back Face (A5): 9 mm Width at Bore Diameter (A6): 12 mm Diameter of Seal Groove (Dc): 80.5 mm Dowel Pins: Distance Between Dowel Pins (J6): 234 mm Axial Offset of Dowel Pins (J7): 27 mm Maximum Diameter of Dowel Pins (N4): 8 mm Breaking Loads: P0°: 210 kN P55°: 300 kN P90°: 180 kN P120°: 130 kN P150°: 120 kN P180°: 150 kN Pa: 100 kN Yield Points of Cap Bolts: Q120°: 220 kN Q150°: 125 kN Q180°: 110 kN Housing Mass: 5.61 kg Recommended Attachment Bolt Diameter (G): 16 mm Recommended Tightening Torque for Attachment Bolts: 200 Nm Size of Cap Bolts: M12x60 Tightening Torque for Cap Bolts: 80 Nm Initial Grease Fill (20%): 80 g Initial Grease Fill (40%): 135 g Included Products: Grease Fitting AH 1/8-27 PTF​ This housing is ideal for applications requiring a durable and cost-effective bearing arrangement. Its easy installation and maintenance features make it a preferred choice in various industries.​
